HUASHUO ROG Strix B650E-F Gaming WiFi Prime B650-P I Prime B650-P AMD AM5 ATX Motherboard DDR5 PCIe 5.0 WiFi 6
HUASHUO ROG Strix B650E-F Gaming WiFi Prime B650-P I Prime B650-P AMD AM5 ATX Motherboard DDR5 PCIe 5.0 WiFi 6 - Image 2
HUASHUO ROG Strix B650E-F Gaming WiFi Prime B650-P I Prime B650-P AMD AM5 ATX Motherboard DDR5 PCIe 5.0 WiFi 6 - Image 3
HUASHUO ROG Strix B650E-F Gaming WiFi Prime B650-P I Prime B650-P AMD AM5 ATX Motherboard DDR5 PCIe 5.0 WiFi 6 - Image 4
HUASHUO ROG Strix B650E-F Gaming WiFi Prime B650-P I Prime B650-P AMD AM5 ATX Motherboard DDR5 PCIe 5.0 WiFi 6 - Image 5
HUASHUO ROG Strix B650E-F Gaming WiFi Prime B650-P I Prime B650-P AMD AM5 ATX Motherboard DDR5 PCIe 5.0 WiFi 6 - Image 6

HUASHUO ROG Strix B650E-F Gaming WiFi Prime B650-P I Prime B650-P AMD AM5 ATX Motherboard DDR5 PCIe 5.0 WiFi 6

  1. Chipset Features:

    • B650E (Strix) guarantees PCIe 5.0 support

    • Standard B650 has limited PCIe 5.0

  2. Form Factors:

    • Strix/Prime-P: Full ATX expandability

    • Prime-P I: Compact ITX for SFF builds

  3. Power Delivery:

    • Strix: Best for Ryzen 9 processors

    • Prime: Suitable for Ryzen 5/7

  4. Networking:

    • Strix has premium WiFi 6E

    • Prime-P I includes WiFi 6 in compact form

  5. Target Users:

    • Strix: Enthusiast gamers

    • Prime-P: Business/office systems

    • Prime-P I: Compact gaming/media PCs

Recommendations:

  • For high-end gaming: ROG Strix B650E-F

  • For budget ATX builds: Prime B650-P

  • For small form factor: Prime B650-P I

Request Best Price
SKU: N/A Category:

HUASHUO ROG Strix B650E-F Gaming WiFi Prime B650-P I Prime B650-P AMD AM5 ATX Motherboard DDR5 PCIe 5.0 WiFi 6



Here’s a detailed comparison table for these AMD AM5 motherboards:

ASUS AM5 Motherboard Comparison Table

Feature ROG Strix B650E-F Gaming WiFi Prime B650-P Prime B650-P I (ITX)
Chipset AMD B650E AMD B650 AMD B650
Form Factor ATX (30.5×24.4cm) ATX (30.5×24.4cm) Mini-ITX (17×17cm)
VRM Design 12+2 phase (80A) 10+1 phase (60A) 8+2 phase (50A)
Memory Support DDR5-6400+(OC) DDR5-6000(OC) DDR5-5600
PCIe Slots 1× PCIe 5.0 x16
1× PCIe 4.0 x4		 1× PCIe 4.0 x16
1× PCIe 3.0 x1		 1× PCIe 4.0 x16
M.2 Slots 3 (1× PCIe 5.0 + 2× PCIe 4.0) 2 (1× PCIe 5.0 + 1× PCIe 4.0) 1 (PCIe 4.0)
SATA Ports 4 4 2
Networking 2.5G LAN + WiFi 6E 1G LAN 2.5G LAN + WiFi 6
USB Ports 1× USB4 40Gbps
9× USB 3.2		 1× USB 3.2 Gen2x2
6× USB 3.2		 1× USB 3.2 Gen2
4× USB 3.2
Audio Realtek ALC4080 Realtek ALC897 Realtek ALC897
Cooling VRM heatsink + M.2 heatsinks Basic VRM heatsink Compact heatsink
RGB Lighting 3× ARGB headers 1× ARGB header None
Special Features AI Overclocking
Q-LED debug		 Business stability Compact design
Price Range $279-$329 $159-$189 $179-$209

1. ROG Strix B650E-F Gaming WiFi (Premium ATX)

The Enthusiast’s Choice

  • Chipset: AMD B650E (PCIe 5.0 guaranteed)

  • Power Delivery: 12+2 phase VRM (80A) – Handles Ryzen 9 7950X with ease

  • Memory: DDR5-6400+ OC support via AEMP

  • Storage:

    • 3x M.2 slots (1x PCIe 5.0 + 2x PCIe 4.0)

    • 4x SATA ports

  • Networking:

    • 2.5G LAN (Realtek RTL8125BG)

    • WiFi 6E (6GHz) + Bluetooth 5.2

  • Expansion:

    • PCIe 5.0 x16 (reinforced slot)

    • USB4 40Gbps Type-C

  • Cooling: Large VRM heatsink + M.2 thermal pads

  • Best For: High-end gaming rigs and content creation

2. PRIME B650-P (Mainstream ATX)

The Business Workhorse

  • Chipset: AMD B650 (PCIe 4.0 only)

  • Power Delivery: 10+1 phase (60A) – Good for Ryzen 7

  • Memory: DDR5-6000 support

  • Storage:

    • 2x M.2 (1x PCIe 5.0 + 1x PCIe 4.0)

    • 4x SATA

  • Networking: 1G LAN (Realtek 8111H)

  • Features:

    • Basic heatsink design

    • 6-layer PCB

  • Best For: Office workstations and budget gaming builds

3. PRIME B650-P I (Mini-ITX)

The Compact Solution

  • Form Factor: Mini-ITX (17×17cm)

  • Power Delivery: 8+2 phase (50A) – For Ryzen 5/7

  • Memory: DDR5-5600 (2 DIMMs)

  • Storage:

    • 1x M.2 PCIe 4.0

    • 2x SATA

  • Networking:

    • 2.5G LAN (Realtek)

    • WiFi 6 (no 6GHz)

  • Unique:

    • Rear USB-C 10Gbps

    • Compact VRM cooling

  • Best For: Small form factor builds and HTPCs

Comparison Summary

Feature ROG Strix B650E-F PRIME B650-P PRIME B650-P I
VRM 12+2 (80A) 10+1 (60A) 8+2 (50A)
PCIe 5.0 GPU + 1x M.2 None None
WiFi 6E None WiFi 6
USB4 Yes No No
Price $299-$329 $159-$189 $179-$209

Key Takeaways:

  • The ROG Strix dominates with PCIe 5.0 and premium features

  • Prime B650-P offers best value for ATX builds

  • Prime B650-P I is the only ITX option shown here

  • All support AMD EXPO for memory overclocking

Recommendations:

  • For maximum performance: ROG Strix B650E-F

  • For budget ATX builds: Prime B650-P

  • For SFF enthusiasts: Prime B650-P I (though limited to PCIe 4.0)

ROG Strix B650E-F Gaming WiFi

Prime B650-P, Prime B650-P I, ROG Strix B650E-F Gaming WiFi
