Original Factory Gigabyte B760M AORUS PRO AX B760M A ELITE AX-PMotherboard DDR5 Supports CPU 1390013700KF Intel B760 LGA 1700
Here’s a comparison table for the GIGABYTE B760M AORUS PRO AX and B760M AORUS ELITE AX-P motherboards:
| Feature | B760M AORUS PRO AX | B760M AORUS ELITE AX-P |
|---|---|---|
| Form Factor | Micro-ATX (mATX) | Micro-ATX (mATX) |
| Socket | LGA 1700 (Intel 12th/13th/14th Gen) | LGA 1700 (Intel 12th/13th/14th Gen) |
| Power Delivery | 12+1+1 Phase VRM (60A DrMOS) | 12+1+1 Phase VRM (60A DrMOS) |
| Memory Support | DDR5 (Up to 7600+ MHz, XMP) | DDR5 (Up to 7600+ MHz, XMP) |
| PCIe Slots | 1x PCIe 5.0 x16 (Steel Armor) | 1x PCIe 5.0 x16 (Steel Armor) |
| M.2 Slots | 3x (PCIe 4.0 x4, 1x with Thermal Guard) | 2x (PCIe 4.0 x4, 1x with Thermal Guard) |
| SATA Ports | 4x SATA 6Gbps | 4x SATA 6Gbps |
| Networking | Intel 2.5GbE LAN + Wi-Fi 6E | Intel 2.5GbE LAN + Wi-Fi 6E |
| Audio | Realtek ALC897 (High-End Audio) | Realtek ALC897 (High-End Audio) |
| USB Ports | – 1x USB-C (20Gbps, Rear) – 1x USB-C (10Gbps, Front) – Multiple USB 3.2 Gen 2/1 |
– 1x USB-C (10Gbps, Rear) – 1x USB-C (5Gbps, Front) – Multiple USB 3.2 Gen 2/1 |
| RGB Lighting | RGB FUSION 2.0 (More Zones) | RGB FUSION 2.0 (Fewer Zones) |
| Cooling | Multiple Fan Headers + Heatsinks | Multiple Fan Headers + Heatsinks |
| BIOS Flashback | ❌ No | ❌ No |
| Price (Approx.) | ~180−200 | ~150−170 |
The GIGABYTE B760M AORUS PRO AX and B760M AORUS ELITE AX-P are both high-performance micro-ATX motherboards designed for Intel’s 12th, 13th, and 14th Gen processors (LGA 1700 socket). They share many premium features, including DDR5 memory support, PCIe 5.0 x16 slots, Wi-Fi 6E, and 2.5GbE LAN, making them excellent choices for mid-range gaming and productivity builds.
Key Similarities:
-
Power Delivery: Both feature a 12+1+1 phase VRM with 60A DrMOS, ensuring stable power delivery for high-end CPUs.
-
Memory Support: DDR5 compatibility with XMP 3.0, supporting speeds up to 7600+ MHz (OC).
-
PCIe 5.0 x16 Slot: Reinforced with steel armor for durability with high-end GPUs.
-
Networking: Intel 2.5GbE LAN + Wi-Fi 6E for fast wired and wireless connectivity.
-
Audio: Realtek ALC897 high-definition audio with noise isolation.
Main Differences:
-
M.2 Slots: The AORUS PRO AX has three PCIe 4.0 M.2 slots (one with a heatsink), while the ELITE AX-P has two.
-
USB-C Speed: The PRO AX includes a 20Gbps USB-C port (rear) and a 10Gbps front header, whereas the ELITE AX-P has a 10Gbps rear port and 5Gbps front header.
-
RGB Lighting: The PRO AX offers more extensive RGB Fusion 2.0 lighting zones for better customization.
-
Price: The ELITE AX-P is slightly more budget-friendly, making it ideal for cost-conscious builders.
Which One Should You Choose?
-
For Enthusiasts & High-End Builds → B760M AORUS PRO AX (better storage options, faster USB-C, enhanced RGB).
-
For Budget Gamers & Mainstream Users → B760M AORUS ELITE AX-P (similar core features at a lower price).
Both boards deliver excellent performance, but the PRO AX is the better choice if you need extra M.2 slots and faster connectivity, while the ELITE AX-P is a great value alternative.
