WholesaleGIGABYTE B550M AORUS ELITE B550M GAMING X WIFI6 Desktop Motherboard AMD B550 Chipset Supports CPU DDR4 Memory SATA Hard for Gaming 128GB
Here’s a detailed comparison table between the GIGABYTE B550M AORUS ELITE and GIGABYTE B550M GAMING X WIFI6 motherboards:
| Feature | B550M AORUS ELITE | B550M GAMING X WIFI6 |
|---|---|---|
| Form Factor | Micro-ATX (24.4 x 24.4 cm) | Micro-ATX (24.4 x 24.4 cm) |
| Chipset | AMD B550 | AMD B550 |
| Socket | AM4 (Ryzen 3000/5000/5000G) | AM4 (Ryzen 3000/5000/5000G) |
| Memory Support | DDR4 (4 DIMMs, up to 4733MHz) | DDR4 (4 DIMMs, up to 4733MHz) |
| PCIe Slots | 1x PCIe 4.0 x16 (Steel Slot) 1x PCIe 3.0 x16 (x4 mode) |
1x PCIe 4.0 x16 (Steel Slot) 1x PCIe 3.0 x1 |
| M.2 Slots | 1x PCIe 4.0 x4 (2280) 1x PCIe 3.0 x4 (22110) |
1x PCIe 4.0 x4 (2280) 1x PCIe 3.0 x4 (22110) |
| SATA Ports | 4x SATA 6Gbps | 4x SATA 6Gbps |
| USB Ports | 1x USB-C (Rear) 4x USB 3.2 Gen1 2x USB 2.0 |
1x USB-C (Rear) 4x USB 3.2 Gen1 2x USB 2.0 |
| Networking | Realtek 1G LAN | Wi-Fi 6 (802.11ax) Realtek 1G LAN |
| Audio | Realtek ALC897 (7.1-Channel) | Realtek ALC897 (7.1-Channel) |
| RGB Headers | 2x ARGB (5V) 2x RGB (12V) |
1x ARGB (12V) 1x RGB (12V) |
| Display Outputs | 1x HDMI, 1x DP | 1x HDMI, 1x DP |
| VRM & Power Design | 6+2 Phase VRM | 6+2 Phase VRM |
| Cooling | Hybrid Fan Headers | Hybrid Fan Headers |
| Price (Approx.) | ~110−140 | ~130−160 |
GIGABYTE’s B550M series offers excellent micro-ATX options for AMD Ryzen builders, balancing performance and features in compact form factors. Here’s a detailed comparison of two popular models:
1. GIGABYTE B550M AORUS ELITE
Best For: Users prioritizing expansion options and RGB lighting in a wired setup
-
Form Factor:Â Micro-ATX (24.4 x 24.4 cm)
-
Networking:Â Realtek 1G LAN (wired only)
-
Key Advantages:
-
Better expansion with additional PCIe x16 slot (x4 mode)
-
Superior RGB support (2x ARGB + 2x RGB headers)
-
Slightly more affordable than WiFi version
-
-
Storage:
-
2x M.2 slots (PCIe 4.0 + PCIe 3.0)
-
4x SATA ports
-
-
Connectivity:
-
USB-C (rear), 4x USB 3.2 Gen1, 2x USB 2.0
-
HDMI + DisplayPort outputs
-
-
Cooling:Â Hybrid fan headers with decent VRM cooling
-
Price: ~110−140
Ideal For:Â Budget-conscious builders who need good expansion and RGB in a wired environment.
2. GIGABYTE B550M GAMING X WIFI6
Best For: Users needing wireless connectivity in a compact build
-
Form Factor:Â Micro-ATX (24.4 x 24.4 cm)
-
Networking:Â Wi-Fi 6 (802.11ax) + 1G LAN
-
Key Advantages:
-
Built-in WiFi 6Â for wireless flexibility
-
Similar core specs to AORUS ELITE
-
Steel-reinforced PCIe slot
-
-
Storage:
-
2x M.2 slots (PCIe 4.0 + PCIe 3.0)
-
4x SATA ports
-
-
Connectivity:
-
USB-C (rear), 4x USB 3.2 Gen1, 2x USB 2.0
-
HDMI + DisplayPort outputs
-
-
Cooling:Â Hybrid fan headers with decent VRM cooling
-
Price: ~130−160
Ideal For:Â Compact builds where wireless connectivity is important, or for users in spaces where running Ethernet isn’t practical.
Key Differences Summary
| Feature | AORUS ELITE | GAMING X WIFI6 |
|---|---|---|
| Networking | 1G LAN only | WiFi 6 + 1G LAN |
| PCIe Slots | Extra x16 (x4 mode) | Standard layout |
| RGB | 2x ARGB + 2x RGB | 1x ARGB + 1x RGB |
| Price | More affordable | Slightly more expensive |
Which One Should You Choose?
-
Choose AORUS ELITE if:
-
You don’t need WiFi
-
Want better RGB control
-
Need the extra PCIe slot
-
Are on a tighter budget
-
-
Choose GAMING X WIFI6 if:
-
You need wireless connectivity
-
Don’t require the extra PCIe slot
-
Are okay with basic RGB options
-
Can spend slightly more for WiFi convenience
-
