Brand new MSI B550M-A PRO B450M-A PRO MAX II Motherboard Supports 5th Generation CPU DDR4 Memory for Desktop
Here’s a detailed comparison table for the MSI B550M-A PRO, B450M-A PRO MAX II, and their key differences:
| Feature | MSI B550M-A PRO | MSI B450M-A PRO MAX II | Winner |
|---|---|---|---|
| Chipset | AMD B550 | AMD B450 | B550 (Newer) |
| Socket | AM4 | AM4 | Tie |
| CPU Support | Ryzen 3000/5000/5000G | Ryzen 3000/5000 (No PCIe 4.0) | B550 (Full Support) |
| PCIe Version | PCIe 4.0 (x16 GPU + M.2) | PCIe 3.0 (All Slots) | B550 (Faster) |
| Memory Support | DDR4-5100+ (OC) | DDR4-4133+ (OC) | B550 (Higher Speed) |
| M.2 Slots | 1x PCIe 4.0 x4 | 1x PCIe 3.0 x4 | B550 (Faster SSD) |
| SATA Ports | 4x SATA III | 4x SATA III | Tie |
| USB Connectivity | 1x USB 3.2 Gen2 (10Gbps) | 1x USB 3.2 Gen1 (5Gbps) | B550 (Faster USB) |
| VRM Design | 8+2 Phase (DrMOS) | 6+2 Phase | B550 (Better Cooling) |
| LAN | Realtek 8111H (1G) | Realtek 8111H (1G) | Tie |
| Audio | Realtek ALC892 (7.1ch) | Realtek ALC892 (7.1ch) | Tie |
| Fan Headers | 1x CPU, 1x System | 1x CPU, 1x System | Tie |
| RGB Support | No | No | Tie |
| BIOS Flashback | No | Yes (MAX II Feature) | B450 (Easier Updates) |
| Price | ~90−100 | ~70−80 | B450 (Cheaper) |
MSI B550M-A PRO: The Modern Budget Workhorse
Best for: Users wanting PCIe 4.0 support and better future-proofing
Key Advantages:
✅ PCIe 4.0 Ready – Full support for faster GPUs and NVMe SSDs
✅ Stronger Power Delivery – 8+2 phase VRM handles up to Ryzen 7 5800X
✅ Faster Memory Support – Officially supports DDR4-5100+ (OC)
✅ 10Gbps USB – USB 3.2 Gen2 for faster external storage
Ideal For:
-
Budget builds with Ryzen 5 5600/5600X or Ryzen 7 5800X
-
Users who want PCIe 4.0 for future GPU/SSD upgrades
-
Workstations needing faster USB connectivity
Limitations:
❌ No BIOS Flashback button
❌ Basic audio (ALC892)
❌ Only 4 SATA ports
MSI B450M-A PRO MAX II: The Value Champion
Best for: Ultra-budget builds with older Ryzen CPUs
Key Advantages:
✅ BIOS Flashback – Update BIOS without CPU installed
✅ Proven Reliability – Mature B450 platform
✅ Lower Price – Typically $20+ cheaper than B550
✅ Good Enough for Ryzen 5 – Handles 5600/3600 fine
Ideal For:
-
Entry-level gaming PCs with Ryzen 5 3600/5500
-
Office/Productivity builds
-
Users who don’t need PCIe 4.0
Limitations:
❌ PCIe 3.0 only (slower for new GPUs/SSDs)
❌ Weaker VRMs (6+2 phase)
❌ Slower USB (5Gbps max)
Which Should You Buy?
Choose B550M-A PRO if:
-
You’re using a Ryzen 7 CPU
-
You want PCIe 4.0 for future upgrades
-
Faster USB/storage matters to you
Choose B450M-A PRO MAX II if:
-
You’re on a tight budget
-
Using Ryzen 5 or older CPUs
-
Don’t care about PCIe 4.0
-
Need BIOS Flashback for easier updates
Price Comparison:
-
B550M-A PRO: ~90−100
-
B450M-A PRO MAX II: ~70−80
