MSI B650 GAMING PLUS DDR5 B650I EDGE WIFI GAMING PLUS WIFI DDR5 PCIE 5.0 ATX Mainboard B650 PC Support RY-ZEN 9000/8000/7000 AM5 Processor
Here’s a detailed comparison table for the MSI B650 GAMING PLUS DDR5 (ATX) and MSI B650I EDGE WIFI DDR5 (Mini-ITX) motherboards:
| Feature | MSI B650 GAMING PLUS DDR5 (ATX) | MSI B650I EDGE WIFI DDR5 (Mini-ITX) |
|---|---|---|
| Chipset | AMD B650 | AMD B650 |
| Socket | AM5 (Ryzen 7000/8000 series) | AM5 (Ryzen 7000/8000 series) |
| Form Factor | ATX (30.5 x 24.4 cm) | Mini-ITX (17.0 x 17.0 cm) |
| Memory Support | DDR5 (Up to 6400+ MHz, OC) | DDR5 (Up to 6400+ MHz, OC) |
| PCIe Slots | 1x PCIe 4.0 x16 (Steel Armor) | 1x PCIe 4.0 x16 (Steel Armor) |
| M.2 Slots | 2x M.2 (PCIe 4.0) | 2x M.2 (PCIe 4.0) |
| SATA Ports | 6x SATA III | 4x SATA III |
| USB Ports | – 1x USB 3.2 Gen2x2 (20Gbps, Type-C) – 5x USB 3.2 Gen2 (10Gbps) – 4x USB 2.0 |
– 1x USB 3.2 Gen2x2 (20Gbps, Type-C) – 3x USB 3.2 Gen2 (10Gbps) – 2x USB 2.0 |
| Networking | – 2.5G LAN (Realtek) – No Wi-Fi |
– Wi-Fi 6E – 2.5G LAN (Realtek) |
| Audio | Realtek ALC897 (7.1ch) | Realtek ALC4080 (7.1ch, Hi-Fi) |
| VRM & Power Design | 12+2+1 Phase (80A SPS) | 8+2+1 Phase (90A SPS) |
| RGB Lighting | Mystic Light (ARGB headers) | Mystic Light (ARGB headers) |
| Cooling & Fan Headers | 6x PWM headers | 3x PWM headers |
| Price Tier | Budget-Mid Range | Premium Compact Build |
MSI B650 GAMING PLUS DDR5 – Affordable ATX Performance
The MSI B650 GAMING PLUS DDR5 is a budget-friendly ATX motherboard designed for gamers and builders who want solid AM5 performance without premium pricing. Built on AMD’s B650 chipset, it supports Ryzen 7000/8000 series CPUs with DDR5 memory and PCIe 4.0 connectivity.
-
Balanced Power Delivery: A 12+2+1 phase VRM with 80A Smart Power Stages ensures stable power for mainstream CPUs and light overclocking.
-
Expansion & Storage: Features 6x SATA ports and 2x M.2 PCIe 4.0 slots, along with a reinforced PCIe 4.0 x16 slot for GPUs.
-
High-Speed Networking: Equipped with a 2.5G LAN port but lacks built-in Wi-Fi (PCIe expansion required).
-
Basic Audio: Uses the Realtek ALC897 codec, sufficient for casual gaming and media.
-
RGB & Cooling: Supports Mystic Light ARGB and includes 6x fan headers for airflow control.
Ideal for:Â Budget-focused ATX builds that prioritize expansion over Wi-Fi.
MSI B650I EDGE WIFI DDR5 – Premium Mini-ITX for Compact Builds
The MSI B650I EDGE WIFI DDR5 is a high-end Mini-ITX motherboard for small-form-factor (SFF) enthusiasts who refuse to compromise on features. Despite its compact size, it packs PCIe 4.0, Wi-Fi 6E, and superior power delivery.
-
Efficient Power Design: 8+2+1 phase VRM with 90A SPS—exceptional for Mini-ITX, supporting even high-core-count Ryzen CPUs.
-
Dual M.2 & 2.5G LAN: 2x PCIe 4.0 M.2 slots and 4x SATA ports maximize storage in a tiny footprint.
-
Advanced Networking:Â Wi-Fi 6E + 2.5G LANÂ for wireless/wired high-speed connectivity.
-
Premium Audio:Â Realtek ALC4080Â codec delivers better sound quality than the Gaming PLUS.
-
RGB & Cooling: Mystic Light ARGB support but only 3x fan headers due to space constraints.
Ideal for:Â Compact gaming PCs, HTPCs, or portable workstations needing Wi-Fi 6E and strong VRMs.
Which One Should You Choose?
-
Pick the B650 GAMING PLUS if:
-
You need an ATX board with more SATA/PCIe slots.
-
You’re on a budget and don’t need Wi-Fi.
-
You prioritize airflow with extra fan headers.
-
-
Pick the B650I EDGE WIFI if:
-
You’re building a Mini-ITX/SFF PC.
-
You want Wi-Fi 6E + 2.5G LAN out of the box.
-
You need better audio and efficient power delivery in a small package.
-
